Electric operation table

  • Features
  • Highlights
  • Quality control
  • Warranty

Technical parameters
External size (L×W) 2100×520mm
Height adjustment (Via Electric-Hydraulic) 600-1120 mm
Reverse Trendelenburg/Trendelenburg 0°-25°/0°-25°
Bed Rotation 0°-180°
Lateral Tilt Left/Right 0°-20°/0°-20°
Head Plate Up/Down 0°-45°/0°-90°
Back Plate Up/Down 0°-75°/0°-20°
Foot Plate Up/Down 0°-15°/0°-90°
Foot Plate Horizontal Positioning ≥90°
Horizontal sliding
0-400 mm
Patient Weight Capacity  250kg

Technical configuration
Anaesthesia Screen 1pc
Hand Remote 1pc
Kidney Bridge 1pc
Arm Support 2pcs
Foot Support 2pcs
Mattress 1set
Shoulder Support 1pair
Fixing Clamp 7pcs
Power Line 1pc
