Opotional
*Weighing system
*Bed extension 20cm
*Back-up battery
*Nurse control panel
*Hand controller
*Emergency stop button
*Cardiac chair position
*Directional wheels function
*5th and 6th extra side rail for full protection
*Monkey pole
*Balkan frame
*Linen holder
*One-button for patient mobilisation position
*One button nursing position
Technical parameters
Technical configuration
*Weighing system
*Bed extension 20cm
*Back-up battery
*Nurse control panel
*Hand controller
*Emergency stop button
*Cardiac chair position
*Directional wheels function
*5th and 6th extra side rail for full protection
*Monkey pole
*Balkan frame
*Linen holder
*One-button for patient mobilisation position
*One button nursing position
Technical parameters
External size (LxWxH) | 2150x1060x390-840 mm |
Mattress platform | 1925x880 mm |
Safe working load | 250 kg |
Back-rest adjustment | 0-75° (±10°) |
Knee-rest adjustment | 0-33° (±10°) |
Reverse Trendelenburg | 0-17° |
Trendelenburg | 0-17° |
Angle indicator | 0-90° |
Auto-regression | 70+40mm |
Position line | 30° |
Voltage and frequency | 100-240 V · 50/60 Hz |
Plug as required (hospital grade) |
Technical configuration
Linear motor | 4pcs |
5'' double side castors, central locking system | 4pcs |
PP oasis side rail extra height | 1set |
PP oasis bed ends with safe lock | 1set |
PP bed platform, removable & washable | 9pcs |
Plastic socket inside PP guardrail for phone or glasses | 2pcs |
X-ray transparent phenolic resin back platform | 1set |
Patent angle indicator for back-rest and trendelenburg position | 4pcs |
Φ113mm wall bumper wheel | 4pcs |
Central locking pedal | 2pcs |
ABS mattress stopper | 2pcs |
Hand controller | 1pc |
I V pole | 1set |
I V pole prevision | 4pcs |
Drainage hook | 2pcs |
Manual CPR | |
Electric CPR | |
Lowest position indicator |
