Medical Equipment

  • Features
  • Highlights
  • Quality control
  • Warranty

Technical parameters
Type,color temperature and lifespan of back light Super bright SMD LED 780 pieces/unit;8000K color temperature;lightsource life of 100,000 hours
Power supply voltage and frequency Global voltage adaptivebuilt-in power supply;AC90V-240V50/60Hz
Adjustment range of viewing screen brightness Adopting PWM dimming technology,100 levels of infinitely adjustable brightness range 0~6000cd/m2
Automatic induction The screen automatically lights up when inserting the film and turns off automatically when taking out the film
Display panel Equipped with a 1.77-inch color LCD panel, which displays the status of dimming, sensing and delay functions, and is easy and intuitive to operate.
Uniformity of brightness of viewing screen ≥90%
Clip device Soft silicone self-locking clip device
Installation method Wall-mounted,bracket type (optional)
Suitable film Ordinary analog X-ray film,high-density digital X-ray film,mammography breast medical film
