Suction apparatus

  • Features
  • Highlights
  • Quality control
  • Warranty

Technical parameters
Power voltage AC110-220V±22V
Rated frequency 50-60Hz
Suction pump 0il-freepiston pumg
Negative pressure ≥0.09MPa(680mmHg)
Range ofnegative pressure 0.02MPa-limit negative pressure value
Noise ≤60dB
Suction rate ≥20L/Min
Storage bottle capacity 2500mL/piece,set of 2,high temperature resistant glass
Intermittent loading continuous operation Short operationtime,maximum operation time 30min,duration 50%
Classification of safety protection Classl equipment,type Bapplied part
Environmentaltemperature range -40~60℃
Relative Humidity Range ≤90%
Atmospheric pressure range 500~1060hPa
Weight 13kg
Packagesize 450X400X600mm



Technical configuration
Suction flexible catheter(length 2M, Φ7×13) 1 pc
Empty foot switch 1 pc
Air filter 2 pcs
Fuse 2 pcs
Chest suction tube 1 pc
